Indoor 48 Core G657A2 LSZH Armoured Fiber Optic Cable

Ask Lasest Price
Brand Name :	DAWNERGY
Model Number :	GJFZY-48G.657A2
Certification :	CE/TELCORDIA
Price :
Payment Terms :	T/T, L/C, D/A, D/P
Supply Ability :	10,000KM PER DAY
Delivery Time :	10-20 work days

Add to Cart

Product Details
Company Profile

Indoor 48 Core G657A2 LSZH Armoured Fiber Optic Cable

Indoor optical cable 48 Fibers G657A2 GJFZY-48G.657A2

1.

Identification	GJFZY-48G.657A2
Application	Indoor optical cable
Configuration	Subunit with max 8 fibers per micro tube, filled with aramid yarn as strength member Subunit sheath: LSZH Wrap tape: water blocking tape Center Strength member: FRP coated with plastic Outer sheath: LZSH, orange Pantone 136C
Temperature Range	Storage and transport -20 to +70°C	Installation -20 to +60°C	Operation -20 to +70°C
Standards	IEC 60793-1, IEC 60793-2, IEC 60794-2-20
Specification No.	GL20200825323
Customer Reference	Common standard

Dimensions

Number of fibers		48
Subunit x fibers		6x8
Outer diameter	mm	9.5±0.5
Weight	kg	80±15%

Note: sheath thickness not consider ripcord portion, sizes and values without tolerances are nominal values

Mechanical Properties

Max. tensile load		Short term:1200N
Crush resistance / 10 cm		Short term:1000 N
Bending radius (installation)		20x cable Ø
Bending radius (operation)		10x cable Ø

See Point 6: Test Methods

Marking

Optical Fiber

Standard	ITU-T G.657A2 UBIF^®R7.5
Optical	Fibre attenuation .. cabled	@ 1310 nm ≤0.40 dB/km	@ 1550 nm ≤0.30 dB/km
	Mode field diameter (MFD)	(8.6~9.2) ± 0.4 µm @1310nm
	Zero dispersion wavelength	1300~1324 nm
	Zero dispersion slope	≤0.092 ps/nm² ∙km
	Polarization mode dispersion (PMD)	≤0.2 ps/√km
	Cable cut-off wavelength	≤1260 nm
	Macro bending loss .. 10 turns Ø30 mm .. 1 turn Ø20 mm .. 1 turn Ø15 mm	@1550 nm ≤0.03 dB ≤0.10 dB ≤0.50 dB	@1625 nm ≤0.10 dB ≤0.20 dB ≤1.00 dB
Geometric	Cladding diameter	125 ± 0.7 µm
	Core/clad concentricity error	≤0.5 µm
	Cladding non-circularity	≤ 1.0 %
Mechanical	Proof stress	≥ 0.69 Gpa

Test Methods

Test	Conditions	Acceptance criteria
Tensile strength IEC 60794-1-2 E1	Tensile strength: see Point 3 Sample length: ≥ 50 m, Duration: 1 min	Fiber strain≤0.6% △α reversible No damage
Crush resistance IEC 60794-1-2 E3	Crush: see Point 3 Test duration: 1 min, number of test: 3	△α reversible No damage
Impact IEC 60794-1-2 E4	Impact energy: 5 J R = 300 mm, number of places/tests: 3	△α reversible No damage
Torsion IEC 60794-1-2 E7	Sample length: 2 m ± 180°, 5 cycles	△α reversible No damage
Repeated Bend IEC 60794-1-2 E6	Bending radius: 20x cable Ø 25 cycles	No damage
Temperature cycling IEC 60794-1-2 F1	-20℃→ +70℃ 12 hours at each step, 2 cycles	△α≤0.2 dB/km and reversible No damage

All optical measurements at 1550 nm (G652D) or 1300 nm (OM2/OM3/OM4)

Logistics

Cable type

Length

Tolerance

2km

-5% / +5%

D*d*B in cm

GJFZY-48G.657A2

Drum Type

Dimensions

Weight

Plywood

92*40*55

Dimensions including protection. Indicative values, actually delivered drum sizes and weights may deviate. Cable ends sealed with caps
